Stationary service center for mounting on the tank or wall.
It is particularly suitable for changing motor oil in larger machines and systems, but can also be used for numerous other fluids.
Function
The pump has two suction lines and two pressure lines. These hose lines connect it to the engine, a used oil tank, and a tank containing fresh engine oil. The arrangement of the pump and lines remains unchanged, regardless of whether used oil is being pumped out or fresh oil is being pumped into the engine. The four lines can be opened and closed by turning the two multifunction taps.
Application
- Engine oil change in CHP units
- Extraction of waste oil from engines, gearboxes, and hydraulics
- Extraction of cooling lubricants
- Machine maintenance
Additional cleaning effect
Unlike when draining the engine oil at the drain plug, pumping out the oil removes more deposits from the engine interior. The negative pressure created by the pump creates a suction effect that draws out dirt.
Small tank 990 l with ADR approval
Equipment:
- Viscomat 70, 230V
- Fuel nozzle for oils with digital counter K400, rigid
- Automatic hose reel 3/4" incl. 8 m hose
Connection accessories:
- Foot valve 1"
- Filter for foot valve 1"
- Suction pipe 1"
- Barrel connection 2"
- Elbow 1“i x 1”a
- Connecting hose 1"
- Screw connection G1“x 1”grommet
- Hose grommet G1“x 1”grommet
Filling set for oils
VISCOMAT 70 oil pump, mounted on a plate for wall mounting
Equipment:
- Filter at pump inlet
- 1.5 m oil-resistant suction hose 1" with foot valve
- 4 m oil-resistant filling hose ¾"
- Filling nozzle for oils with digital counter K400
- Holder for filling nozzle and filling hose
